Product Description
While aluminum fence has become popular for property enclosures
due to its corrosion resistance and weight, steel is a stronger alternative.
With a chemically bonded powder coated finish and zinc phosphate undercoat, a steel fence panel can outlast an aluminum panel even in harsh conditions.
Steel construction allows for longer panels without sag under weight or stress, which also allows for fewer post holes and less labor!
1. Material Of Steel Fencing
High Quality Q235 Galvanized steel pipe
2. Surface treatment ofSteel Fencing
Galvanized and PVC coating
PVC Coating Colors: green, white, black,yellow,red etc.
3.Process of Steel Fencing
The Steel Fencing is made of steel pipes and then assembling by hands. After that, thesurface can
be powder coated into different colors.
A) Fence Panel Process
straighten & cut short the wire-Welding-Bending-Galvanizing- Parkerizing- powder/pvc coating - packing
B) Fence Post Process
cut short the tube-hole frilling-Galvanizing-Sandblasting-powder/pvc coating-rivet nuts installing
4. Property of Steel Fencing
corrosion resisting, aging-resistant,sunshine-resistant and weather-resistant, easy to transport and easy installed.
5. Steel Fencing Specifications
| 1800mm x 2400mm |
| 2100mm x 2400mm |
| 2400mm x 2400mm |
| 3000mm x 2400mm |
Steel Fencing Upright pailings ,Upright pailing picket are crimped spear deterrent uninvitors ,intruders
| 25mm x 25mm x 0.80mm |
| 25mm x 25mm x 1.00mm |
| 25mm x 25mm x 1.20mm |
Steel Fencing rails available 2,3 4rails depand on customer requirements avaiable punched rails and
full weld rails with upright pails
| 40mm x 40mm x 1.2mm |
| 40mm x 40mm x 1.3mm |
| 50mm x 50mm x 1.5mm |
Steel Fencing Post
| 65mm x 65mm x 2.0mm x 2700mm |
| 65mm x 65mm x 2.0mm x 3000mm |
| 100mm x 100mm x 3.0mm x 3000mm |
| 60mm x 60mm x 3000mm |
| 60mm x 60mm x 3000mm |
Steel Fencing accessories Included 1 pcs post caps plus 4 set security bracket and 12 pcs self drilling screw
6. Steel Fencing treatment
Pre-Galvanized then electrostatic powder spray coated
Full Hot dipped galvanized then electrostatic powder spray coated
Residential Fence Grade (G60 Galvanized Steel)
Picket: 16mmx16mmx1.0mm ( 5/8'sq x 19ga)
Rail: 35mmx 35mm x 1.2mm(1-3/8'sq x 18ga)
Post: 50mmx50mmx1.5mm (2'sq x 16ga)
Fence Width: 2400mm(8)
Fence Height(mm): 914mm,1067mm, 1219mm,1372mm,1524mm,1829mm
Fence Height(Feet):3, 3.5, 4, 4.5, 5, 6
- Post enlarged by 25% from 2” to 2-1/2” square
- Post resalesrced by internal rib to resist bending
- Rail enlarged by 25% from 1” to 1-1/4” high
- Rail resalesrced internally to resist side impact
- Picket enlarged by 25% from 5/8” to 3/4” square
- Holes to mount rail eliminated from post design;
replaced by stronger exterior bracket
7. Packaging & Delivery
Packaging Details: In steel pallet
Delivery Time: 15-20 days after receiving the deposit
