Anping DB Metal Fencing Co.,Ltd---Top 5 Fencing Supplier
Place of Origin: | China |
Brand Name: | DB Fencing |
Certification: | ISO9001 |
Model Number: | TF--1912 |
Minimum Order Quantity: | 100 panels |
---|---|
Price: | USD 22-25/set |
Packaging Details: | In steel pallet |
Delivery Time: | 15 days after receiving the deposit |
Supply Ability: | 1000 panels In one week |
Material: | Low Carbon Steel Q235 | Wire Dia.: | 4.0mm |
---|---|---|---|
Mesh Size: | 60x150mm | Frame Tube: | 32x2.0mm |
Size: | 2.1x2.4m | Finish: | Hot Dipped Gal. |
Plastic Feet: | 28 Kgs | Steel Clamps: | Hot Dipped Gal. |
Packing: | In Steel Pallet | Lead Time: | 15 Days |
High Light: | australian standards temporary fencing,temporary site fence panels |
au-temporary-fencing-catalog.pdf
3. Corrosion resistance form: electric galvanized, hot dipped galvanised, PVC coated.
digging holes or laying foundations.
Different specifications are available according to customers' special inquiries or detailed drawings.
1) Temporary fence panel to secure construction sites and private property.
2) Temporary fencing panel of residential housing sites.
3) Temporary fencing panel and crowd control barriers for the major public. events, sports, concerts, festivals, gatherings, etc.
4) Dog Pen for small dog
5) Instead of timber hoarding
6) Installed with temporary fence gate, shade cloth.
7) Australia wide construction hoarding
8) Used in pool area
1. Econo Panel Sets for Sale Complete Temporary Fencing System | |
Design | Australia & New Zealand |
Made | China |
Panel Specification | |
Panel Size | 2400mm(L) x 2100mm(H) |
Frame | 32mm O.D. &1.35mm Wall Thickness Galvanised to NZ standard 42 Microns |
Infill Mesh | 3.0mm horizontal, 3.0mm vertical 150mm x 60mm spacing |
Treatment | Pre-galvanized pipe and panel welded, then galvanized spraying |
Standard | AS&NZ 4687-2007 |
Weight/Panel | 14kgs |
2. 3.5 Lighter Sets for Sale Complete Temporary Fencing System |
Panel Specification | |
Panel Size | 2400mm(L) x 2100mm(H) |
Frame | 32mm O.D. & 1.2mm Wall Thickness Galvanised to NZ standard 42 Microns |
Infill Mesh | 3.5mm horizontal, 3.5mm vertical 150mm x 60mm spacing |
Treatment | Pre-galvanized pipe and panel welded, then galvanized spraying |
Standard | AS&NZ 4687-2007 |
Weight/kgs | 16.5kgs |
3. 3.0 Lighter Sets for Sale Complete Temporary Fencing System | |
Panel Specification | |
Panel Size | 2400mm(L) x 2100mm(H) |
Frame | 32mm O.D. & 1.5mm Wall Thickness Galvanised to NZ standard 42 Microns |
Infill Mesh | 3.0mm horizontal, 3.0mm vertical 150mm x 60mm spacing |
Treatment | Pre-galvanized pipe and panel welded, then galvanized spraying |
Standard | AS&NZ 4687-2007 |
Weight/kgs | 16kgs |
4. Heavy Duty Sets for Sale Complete Temporary Fencing System | |
Panel Specification | |
Panel Size | 2400mm(L) x 2100mm(H) |
Frame | 32mm O.D. & 2.0mm Wall Thickness Galvanised to NZ standard 42 Microns |
Infill Mesh | 4.0mm horizontal, 4.0mm vertical 150mm x 60mm spacing |
Treatment | Pre-galvanized pipe and panel welded, then galvanized spraying |
Standard | AS&NZ 4687-2007 |
Weight/kgs |
20kgs |
There are many color options for plastic feet for you to choose from, like orange, yellow, blue, etc.
|
|
1. Temporary Fence Base Filled With Water |
2. Temporary Pool Fence Block Filled With Concrete |
|
|
3. Temporary Fence Feet Filled With Concrete |
4. Injection Temporary Fence Feet Filled With Concrete |
High-quality Temporary Fence Clamps are used to secure the panels together.
Center distance available: 75mm, 90mm, 100mm etc.
|
|
1. Temporary Fence Galvanized & Powder Coated Clamps |
2. Temporary Fence Panel With Clamps |
High-quality Temporary Fence Stays are used to support the temporary fence in high wind areas.
Hot Dipped Galvanized to Australian Standard - 42 Microns.
Specially designed for extra strength so fence stands up in very high winds.
Each Stay requires 2 Clamps and 3 Plastic Feet.
